Ag.A 14 Model

Characteristics of the boat:

• Type: Mototopo
• Model: Ag.A 14 made with glass-reinforced plastic

^ top

Boat Plan

Hull:

• Length overall: 12.95 m
• Length of floatation: 12.56 m
• Width outside planking: 2.79 m
• Height of boat: 1.34 m
• Tonnage length: 12.86 m
• Tonnage width: 2.58 m
• Tonnage height: 1.10 m
• Gross tonnage: 9.14 tsl
• Hull made with: glass-reinforced plastic and wood
• Decks: partial aft and prow deck
• Minimal crew members: n. 1
• Max capacity of boat with 1 crew member included (12.95 m version): 20.0 t
• Tiller rudder

^ top

Engine:

• Motor type: diesel inboard engine
• Maximum power of engine: kw. 206 (280 cv)
• Maximun number of engine: n. 1

^ top

Standard equipment:

• Glass-reinforced plastic hull, type-tested by R.I.Na.
• Marine plywood (anti-mould treated) floor
• Glass-reinforced plastic hatches with holes and air inlet
• Glass-reinforced plastic floor under aft and prow deck
• Engine room covered with a liftable hatch
• Command room covered with 1 sliding hatch
• Glass-reinforced wood rudder
• Prebent rubber prow bumper

^ top

Ironware:

• Stainless steel rudder pintle and tiller
• 10 stainless steel mooring staple
• 4 stainless steel bollard

^ top

Command room:

• Glass-reinforced plastic cockpit in order to separate command room from engine room
• Hatches in order to close under aft deck room
• Command pannel
• 2 drawers

^ top

Electrical system:

• Prescribed lights
• 1 prow removable floodlight
• Hooter
• 1 electrical bilge pump
• 1 battery proportionate to engine
• Hold and engine room lights

^ top

Click here for more info about this boat

All the specification in this page are just as indication and not binding.
